Synthetic Winch Rope & Extensions - 1/4", 3/8", 5/16", 7/16" & 1/2"

Synthetic Winch Rope is the Stronger, Lighter and Safer choice when winching. Our winch ropes are made from heavy duty,12 strand synthetic rope that is stronger and also lighter than equivalent steel winch cable.

Our synthetic winch rope is available for all winches from 2500 lbs. to 20,000 lbs. Synthetic winch rope can be used on winches for ATV, UTV, Jeeps, Trucks, off road, military & commercial vehicles.

It is easy to convert steel winch cable to synthetic rope on any winch. All of our synthetic winch ropes are direct replacements for worn out or damaged synthetic ropes and meet or exceed winch manufacturers specifications. Check out our Winch Rope Conversion Chart to find out what size winch rope you need for your model winch

Don’t See What You Need? Click Here to go to our Custom Winch Rope Order Form

Synthetic Winch Rope is Stronger, Lighter and Safer

Stronger:

Synthetic Winch Rope has a Breaking Strength up to 30% more than steel winch cable of equal size. Synthetic Winch Rope is constructed of a unique ultra high molecular weight polyethylene material. UHMWPE is an extremely high-strength, low-stretch rope ( less than 5%) that offers high abrasion resistance and great tensile strength. Each Synthetic Winch Rope is coated in UV Resistant urethane to protect the fibers from sun exposure. Synthetic winch rope is resistant to damage from most oils and chemicals and does not corrode like steel cable.

Lighter:

Our UHMWPE made Winch Ropes are up to 85% Lighter than equivalent steel cable. Synthetic rope is light enough that it floats on water. Synthetic rope is the perfect replacement for steel cable when weight is an issue.

Safer:

Synthetic Winch Rope is a much Safer alternative to using steel cable due to its low weight, low stretch and recoil. Our ropes weigh up to 85% less than steel cable and its low stretch does not allow for a large amount of kinetic energy to build up. Our Synthetic ropes 12 strand design nearly eliminates the recoil that is found on steel cable due to its twisted construction. Steel cable releases a violent and uncontrollable untwisting motion when it breaks increasing the likelihood of damage and injury while winching. Our winch rope does not burr or splinter like cable. Synthetic rope is also easily repaired or spliced and easier to handle and spool on a winch.

Synthetic Winch Rope Features:

Stronger – 30% Stronger than equivalent steel cable
Lighter – Weighs up to 85% less than steel winch cable
Safer– Torque-free lets the rope more likely to drop to the ground if it ever breaks
Construction – 12 strand UHMWPE synthetic rope
Sizes –  Many Diameters and Lengths 3.16, 1/4, 5/16, 3/8, 7/16 & 1/2
Colors – Black, Silver, Red, Blue, Orange, Yellow, Lime Green, Military Green,  Purple and Pink
Termination Hardware – Choose from Tube Thimble, Soft Eye Loop or Safety Thimble
Hardware – Choose stainless steel drum attachment, loop end or none

Winch Rope Specification by Size

** Each Winch Rope comes pre-assembled and ready for easy installation.

1/4″  Winch Rope:

Use: Winches from 2,000 lbs. To 5,500 lbs. Commonly on ATV & UTV winches
Material: 12 strand UHMWPE Synthetic Rope
Diameter: 1/4 Inch
Lengths: 50 ft. – Custom lengths available by request.
Breaking Strength: 9,000 lbs.
Sheathing: 3 ft. Heavy-Duty Polyester
Color: Black, Silver, Blue, Red, Orange, Yellow,
Working End Hardware: – Tube Thimble, Loop End or Safety Thimble I

3/8″  Winch Rope:

Use: Winches from 6,000 lbs. To 12,000 lbs.
Material: 12 strand UHMWPE Synthetic Rope
Diameter: ⅜ Inch
Lengths: 50 ft, 85 ft., 100 ft., & 125 ft. – Custom lengths available by request.
Breaking Strength: 20,000 lbs.
Sheathing: 8 ft. Heavy-Duty Polyester
Color: Black, Silver, Blue, Red, Orange, Lime Green, Military Green, Yellow, Pink, Purple
Working End Hardware: Steel Tube thimble, Soft Loop or Safety Thimble II
Drum Attachment Hardware: Screw Type Drum Attachment Kit, Loop End  or none

7/16″ Winch Rope:

Use: Winches from 12,000 lbs. To 20,000 lbs.
Material: 12 strand UHMWPE Synthetic Rope
Diameter: 7/16 Inch
Lengths: 90 ft. & 100 ft. – Custom lengths available by request.
Breaking Strength: 26,000 lbs.
Sheathing: 8 ft. Heavy-Duty Polyester
Color: Black & Silver – Custom colors available by request
Termination Hardware – Includes Steel Tube thimble or Optional Safety Thimble II
Hardware – Includes stainless steel drum attachment and hardware

1/2″ Industrial Winch Rope:

Use: Winches 15,000 lbs. and up
Material: 12 strand UHMWPE Synthetic Rope
Diameter: 1/2″ Inch
Lengths: 90 ft & 100 ft. – Custom lengths available by request.
Breaking Strength: 34,000 lbs.
Sheathing: 10 ft. Heavy-Duty Polyester
Color: Orange, Black – Custom Colors available upon request
Working End Hardware –Steel Tube thimble or Loop End
Drum Hardware –Screw Type Drum Attachment Kit, Loop or none

Choosing the Correct Size Winch Rope for Your Winch?
